Selected:

KLQ6121YR

KLQ6121YR

Categories: ,

Description

KLQ6121YR  CATALOGE
 Model(型号)
KLQ6121YR
Overall dimensions(mm)(尺寸) 11740*2500
GVW (KG)(总重量) 16800
complete vehicle curb mass(KG)(整备质量) 12800
Engine (发动机) HINO
Gear Box(变速箱) ZF 6S1310BO
Suspension(悬架) 2*4 air bagand WABCO ABS
Max Speed(KM\H)(最高时速) 120
approach / departure angle(接近角和离去角°) 11.8\10
Wheelbase(mm)(轴距) 5870
Chassis
Item Standard
Engine Model(发动机) HINO J08E-UP 300HP
Power (hp)(马力) 300HP 222KW@2500 rpm, 7684CC
Emission(排放标准) Euro III
Gearbox(变速箱) ZF 6S1310BO
Propeller shaft(传动轴)  Strengthen Propeller Shaft
Retarder(缓速器) TELMA Electric Retarder
Suspension(悬架) 2*4 air bagand WABCO ABS
Steering(转向)  BOSCH Power Steering
Axle(轴)Front & Rear Dongfeng/Fengsheng 6.5T & Dongfenh/Fengsheng 13T,  Front & Rear Disc Brake
Braking(刹车) Dual-circuit Service brake, Spring energy parking brake
Tyre(轮胎) 295/80R22.5 Tubeless
Spare tire(备胎) YES
CAN System(CAN系统) YES
Tank capacity(L)(油箱容量) 440
Air Dry(空气干燥器) WABCO
Lubricating System(润滑系统) YES
Clutch(离合器)  SACHS Diaphragm Spring Clutch 430 mm (17″)
Parking Braking(驻车系统) Energy Storage Spring
ABS(防抱死) WABCO ABS
 Wheel Cover(不锈钢轮罩) Wheel cover Allue Core with ABS sensor
