TRAVELLER T2 4020 WB
Description
ENGINE |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | TRAVELLER T2, Engine: FM 3.2 CR | ||||||||||
| Emission | BS IV | ||||||||||
| Type | 5Cylinder Common rail, Diesel Engine, 3245CC, 114HP,@2800 rpm, GVW-5750KG | ||||||||||
| Displacement | 3245 cc | ||||||||||
| Max Output | 114 hp (95 KW)@ 2800 rpm | ||||||||||
| Max Torque | 300Nm@1600-2400rpm | ||||||||||
TRANSMISSION |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Type | 6 Speed Synchromesh Gearboxes | ||||||||||
| No. of Gears | 5 Forward & 1 Reverse ) | ||||||||||
AXLES |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Front Axle: | Dead Rigid | ||||||||||
| Rear Axle: | Live Rigid | ||||||||||
SUSPENSION |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Front & Rear: | Semielliptic Leaf Spring | ||||||||||
| Shock Absorbers
(Front & Rear) |
Front& Rear Suspension: Semi Elliptical Leaf Springs With Hydraulic Shock Absorber and anti-roll bar | ||||||||||
STEERING & CLUTCH |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Type | Power Steering | ||||||||||
| Clutch type | Dry Friction , Single plate & hydraulically actuated | ||||||||||
BRAKES |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Brakes | Dual Circuit, hydraulic Vacuum assisted with ABS & EBD (optional) | ||||||||||
| Front & Rear | Ventilated Brake Disc on all wheels | ||||||||||
| Parking Brakes | Mechanical | ||||||||||
| price | 37,50,000/= | ||||||||||
WHEELS & TYRES |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Front – Two, Rear- Four, & Spare – one .
Tyres: Radical – 215 / 75 R 15 Wheels : 6.0J x 15 |
|||||||||||
CHASSIS :
Monocoque Varying with box section .
DIMENSIONS(mm) |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Wheel Base | 4020 | ||||||||||
| Overall Length | 6670 | ||||||||||
| Overall Width | 2225 | ||||||||||
| Overall Height | 2870 | ||||||||||
| Gross Vehicle Weight Kg | 5250 | ||||||||||
| Turning Radius (Mts) | 7.00 | ||||||||||
| Ground Clearance | 170 | ||||||||||
CAPACITY |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Fuel Tank | 70 Litres | ||||||||||
SEATING CAPACITY |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Seating Capacity | 26+D | ||||||||||
