TRAVELLER T1 3700 super 17+D
Description
ENGINE |
|||||
|---|---|---|---|---|---|
| Model | FM 2.6 CR | ||||
| Emission | BS IV | ||||
| Type | 4 Cylinder, Common Rail | ||||
| Displacement | 2596 cc | ||||
| Max Output | 90 HP (67 kw) @ 2800 rpm | ||||
| Max Torque | 250 Nm@1400-2400 rpm |
TRANSMISSION |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Type | Synchromesh | ||||||||||
| No. of Gears | 5 Forward-1 Reverse (5th gear – overdrive) | ||||||||||
AXLES |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Front | Dead Rigid, I Beam ( Reverse Elliot Type) | ||||||||||
| Rear | Live Rigid | ||||||||||
SUSPENSION |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Front | Semi Elliptical Leaf Springs with Hydraulic Shock Absorbers and Anti Roll Bar . | ||||||||||
| Rear | Semi Elliptical Leaf Spring with Hydraulic Telescopic Shock Absorbers | ||||||||||
STEERING |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Type | Mechanical / Power Steering (Optional) | ||||||||||
| Turning Radius | 6.5 | ||||||||||
BRAKES |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Service Brakes | Hydraulic- Dual Circuit ,Vacuum Assisted ABS with EBD | ||||||||||
| Front | 4 – Piston, Ventilated, Disc brakes with wear indicator | ||||||||||
| Rear | Drum Brakes | ||||||||||
| Parking | Mechanical, on Rear Wheels | ||||||||||
WHEELS & TYRES |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Size | 215/75 R 15 | ||||||||||
DIMENSIONS(mm) |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Wheel Base | 3700 | ||||||||||
| Overall Length | 6065 | ||||||||||
| Overall Width | 1900 | ||||||||||
| Overall Height | 2770 (With AC) | ||||||||||
| Overhang Front | 900 | ||||||||||
| Overhang Rear | 1465 | ||||||||||
| Ground Clearance | 210 | ||||||||||
WEIGHTS( kg ) |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Max. Permissible FAW | 1780 | ||||||||||
| Max. Permissible RAW | 2280 | ||||||||||
| Max. Permissible GVW | 4060 | ||||||||||
CAPACITY |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Fuel Tank | 70 Liters | ||||||||||
SEATING CAPACITY |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Seating Capacity | D+17 | ||||||||||
